LAWAI is meant to be the top centrifugal casting in Taiwan
The best raw alloys imported from EU
The strong R&D and manufacturing team
The responsible management and sales representatives
Endless support from you ….
Materials of Shaft Bushing
►PLEASE SCROLL DOWN, YOU'LL FIND THE TABLES OF GRADE
300 series, Duplex stainless steel
Custom alloys ( This is what we can do for you )
Dimensions of Shaft Bushing
►ALL ARE CUSTOMIZED
Based on your drawings and requirements
Applications of Shaft Bushing
►WE'LL DO THE BEST TO ASSIST YOU WITH ANY CASE
Marine engineering
Others
Features of Shaft Bushing
Centrifugal casting is without casting defects and holes
One-piece construction - always better than weld
Saving cost beacause of long lifetime
Mechanical properties are almost equal to forging
For the better world, recycled alloys will be used if the project suits
Made in Taiwan is always beyond your expectation
LAWAI ALLOY | Cast Specifications | Wrought Specifications | ||
---|---|---|---|---|
ASTM | UNS | AISI | UNS | |
CF8 | A351/743/744 CF8 | J92600 | 304 | S30400 |
CF3 | A351/743/744 CF3 | J92500 | 304L | S30403 |
CF8M | A351/743/744 CF8M | J92900 | 316 | S31600 |
CF3M | A351/743/744 CF3M | J92800 | 316L | S31603 |
CK20 | A351/743/744 CK20 | J94202 | 310 | S31000 |
CF8C | A351/743/744 CF8C | J92710 | 347 | S34700 |
CG8M | A351/743/744 CG8M | J93000 | 317 | S31700 |
CG3M | A351/743/744 CG3M | J92999 | 317L | S31703 |
CF10SMnN ( Nitronic 60 ) | A351/743/744 | J92972 | ||
CG6MMN ( Nitronic 50 ) | A351/743/744 | J93790 | ||
CN7M (≈ 20Cb-3) | A351/743/744 | N08020 | ||
CF3M-HM | ||||
CH20 (≈ 309) | A351/743 | J93400 | ||
CD20N (≈ CE20N) | A351/451 | N08007 | ||
Nitronic 33 | ||||
Nitronic 40 | ||||
CN7MS | A744 | J94650 | ||
CN3MN | A743/A744 | J94651 | ||
CK3MCuN (≈254SMO) | ||||
RA330 |
LAWAI ALLOY | Cast Specifications | Wrought Specifications | ||
---|---|---|---|---|
ASTM | UNS | AISI | UNS | |
1A CD4MCu | A 351 /A 890 | J93370 | ||
4A CD3MN | A890/A995 4A CD3MN | J92205 | 2205 | S31803 |
CD7MCuN | A890 1C CD3MCuN | J93373 | S32550 | |
1B CD4MCuN | A890/A995 1B CD4MCuN | J93372 | ||
DPX-1B MOD | ||||
5A CE3MN | A890/A995 5A CE3MN | J93404 | 2507 | S32750 |
CE8MN | A890/A995 2A CE8MN | J93345 | ||
CD3MWCuN | A890/A995 6A CD3MWCuN | J93380 | Z100 | S32760 |
LAWAI ALLOY | Cast Specifications | Wrought Specifications | ||
---|---|---|---|---|
ASTM | UNS | AISI | UNS | |
CB7Cu-1 | A747 Gr CB7Cu-1 | J92180 | 17-4PH | S17400 |
CB7Cu-2 | A747 Gr CB7Cu-2 | J92110 | 15-5PH | S15500 |
LAWAI ALLOY | Cast Specifications | Wrought Specifications | ||
---|---|---|---|---|
ASTM | UNS | AISI | UNS | |
CD-2 (≈ D-2 Tool Steel) | A597 CD-2 | T30402 | ||
CD-5 (≈ D-5 Tool Steel) | A597 CD-5 | T30405 | ||
Ni-resist 1 | A436 Type 1 | F41000 | ||
Ni-resist 2 | A436 Type 2 | F41002 | ||
Ni-resist 3 | A436 Type 3 | F41004 | ||
Ni-resist 4 | A436 Type 4 | F41005 | ||
Type D-2 (≈Ductile Ni-Resist) | A439 Type D-2 | F43000 | ||
Type D-2B (≈Ductile Ni-Resist) | A439 Type D2-B | F43001 | ||
Type IIB (≈15-3CrMo White Iron) | A 532 Class IIB | F45005 | ||
Type IIIA (HC-250) | A 532 Class IIIA | F45009 |
